Products

Certified by DNV, LR, BV, RINA and CRS
ARIES
ORION
AQUARIUS
CENTAUR
PHOENIX

ARIES

Flagship marine system for energy applications with high energy density. Good for deep discharge applicaitons such as fully electric ferries or tugboats.
Energy density up to

126 WH/KG

Capacity

230 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Dimensions (W x H x D) in mm 400x235x550
Weight 70kg
Peak Charge rate (30s) 2C
Peak Discharge rate (30s) 2.5C
Max  C Average continuous 0.6C
Energy 8.8kWh
Volumetric Energy Density 170Wh/L
Specific Power 314W/kg
Cycle Life (25°C, 1C/1C to 80% SoH, 100% DoD) 4000

ARIES+

Flagship marine system for energy applications with high energy density. Good for deep discharge applicaitons such as fully electric ferries or tugboats.
Energy density up to

135 WH/KG

Capacity

460 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Dimensions (W x H x D) in mm 520x235x690
Weight 130kg
Peak Charge rate (30s) 1.3C
Peak Discharge rate (30s) 1.3C
Max  C Average continuous 0.43C
Energy 17.6 kWh
Volumetric Energy Density 209Wh/L
Specific Power 176W/kg
Cycle Life (25°C, 1C/1C to 80% SoH, 100% DoD) 4000

ARIES+ s

Flagship marine system for energy applications with high energy density. Good for deep discharge applicaitons such as fully electric ferries or tugboats.
Energy density up to

135 WH/KG

Capacity

460 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Dimensions (W x H x D) in mm 400x235x880
Weight 130kg
Peak Charge rate (30s) 1.3C
Peak Discharge rate (30s) 1.3C
Max  C Average continuous 0.43C
Energy 17.6 kWh
Volumetric Energy Density 209Wh/L
Specific Power 176W/kg
Cycle Life (25°C, 1C/1C to 80% SoH, 100% DoD) 4000
Suitable for
ship powered by ayk energy

Marine application

stationary station

Stationary application

stationary station ship powered by ayk energy

ORION

Marine power battery suitable for high C-rate applications. Good for high peak power applciations such as spinning reserve or peak shaving on Hybrid vessels such as OSVs, drill rigs or hybrid tugboats.
Energy density up to

99 WH/KG

Capacity

180 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Dimensions (W x H x D) in mm 315x235x655
Weight 70kg
Peak Charge rate (30s) 3C
Peak Discharge rate (30s) 3C
Max  C Average continuous 1C
Energy 6.9kWh
Volumetric Energy Density 142Wh/L
Specific Power 296W/kg
Cycle Life (25°C, 1C/1C to 80% SoH, 100% DoD) 6000

ORION+

Marine power battery suitable for high C-rate applications. Good for high peak power applciations such as spinning reserve or peak shaving on Hybrid vessels such as OSVs, drill rigs or hybrid tugboats.
Energy density up to

108 WH/KG

Capacity

270 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Dimensions (W x H x D) in mm 315x235x890
Weight 95kg
Peak Charge rate (30s) 2C
Peak Discharge rate (30s) 2C
Max  C Average continuous 1C
Energy 10.3 kWh
Volumetric Energy Density 156Wh/L
Specific Power 217W/kg
Cycle Life (25°C, 1C/1C to 80% SoH, 100% DoD) 6000
Suitable for
ship powered by ayk energy

Marine application

stationary station

Stationary application

stationary station ship powered by ayk energy

AQUARIUS

Elegent light power application battery with a compact easily manageable module design good for smaller high speed vessles with tight spaces.
Energy density up to

103 WH/KG

Capacity

228 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection

AQUARIUS+

Elegent light power application battery with a compact easily manageable module design good for smaller high speed vessles with tight spaces.
Energy density up to

126 WH/KG

Capacity

560 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Dimensions (W x H x D) in mm 520x235x875
Weight 170kg
Peak Charge rate (30s) 1C
Peak Discharge rate (30s) 1C
Max  C Average continuous 0.35C
Energy 21.5 kWh
Volumetric Energy Density 201Wh/L
Specific Power 126W/kg
Cycle Life (25°C, 1C/1C to 80% SoH, 100% DoD) 6000
Suitable for
ship powered by ayk energy

Marine application

stationary station

Stationary application

stationary station ship powered by ayk energy

CENTAUR

Super high energy terrestrial containerized battery up to 2.8MWh/20' container, good solution for portable battery system, remote microgrids or renewable applications.
Energy density up to

137 WH/KG

Capacity

608 AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Dimensions (W x H x D) in mm 520x235x875
Weight 170kg
Peak Charge rate (30s) 1C
Peak Discharge rate (30s) 1C
Max  C Average continuous 0.35C
Energy 23.3 kWh
Volumetric Energy Density 218Wh/L
Specific Power 137W/kg
Cycle Life (25°C, 1C/1C to 80% SoH, 100% DoD) 4000
Suitable for
stationary station

Stationary application

stationary station

PHOENIX

To be unveiled soon
Energy densities up to

TBA WH/KG

Capacity

TBA AH

LFP battery
HVIL
Air cooling
E-Stop
Gas extraction duct
System voltage
Thermal runaway prevention
High voltage protection
Suitable for
ship powered by ayk energy

Marine application

stationary station

Stationary application

stationary station ship powered by ayk energy

Package contents

Up to 1000VDC

with DC Breaker designed for up to 1500VDC

Thermal runaway and fire protection system

with integrated gas extraction fan

Multi-string manager

with 13” touch screen display

AC sub panel

String controller

with ABB Breaker for protection and isolation

Independent hardware protection

cell over voltage

Pre-charge circuit included
